Project Conquest 4G63T

TicEagle · Post by **TicEagle** » Mon Aug 06, 2007 4:44 pm

Hi, I'm located in Montreal, Canada and I buy a Conquest from USA last years. I have the plan to swap my engine from my Eagle talon in the quest. This is my little story:

This is my old Eagle Talon (I made 426whp without nitrous at the Dsm Shootout on the Buschur Dyno)

The plan is to use a Muncie Rock Crusher M22 manual 4 speed, fit a oem dsm bell housing, use stock flywheel, dsm 2900 pressure plate, custom 6 puck disc and a hydraulic throwout bearing. This is the results:

The total weight of the transmission with the bellhousing and the adaptor plate is 60 pounds. I just buy a new shifter for it. An inline v-gate shifter, no more ''H'' pattern only push-pull style.

I made a custom ss exhaust manifold, I use a Forester Intake manifold, I change my 2.0L engine for a brand new 2.3L, with Hks 272 cams, manual brake master, watercooler and lot lot more stock.

Custom motor mount

I don't want to have trouble with the rear thermostat housing and the waterpipe. I remote all of this things and I made a custom plate to replace the water pump. I run an electric water pump.

I strip all the car

Weld the roll cage and paint every things

Watercell for the water cooler

Manifold (now with Hks 60mm v-clamp)

And the results:

The first start up isn't bad
http://smg.photobucket.com/albums/v635/ ... I_0042.flv
http://smg.photobucket.com/albums/v635/ ... I_0043.flv

Tic

Diamondback · Post by **Diamondback** » Mon Aug 06, 2007 8:00 pm

very nice very sexy car, im jealous

75COLT · Post by **75COLT** » Mon Aug 06, 2007 9:37 pm

cool car. tell me more about the forester intake. did you cut the flange from mits and mate the two?

Ian

TicEagle · Post by **TicEagle** » Tue Aug 07, 2007 8:13 am

No, the Forester intake is made in two piece. It cast. You could change the side of the cover. It's bolt-on on a dsm head.

The bad thing, you could not use the stock brake booster.

TicEagle · Post by **TicEagle** » Tue Aug 07, 2007 11:02 am

It's not a intake manifold from a Subaru Forester but it's a intake manifold made for the dsm brand Forester (FRH)

89coltgt · Post by **89coltgt** » Tue Aug 07, 2007 12:05 pm

Very nice swap.

75COLT · Post by **75COLT** » Tue Aug 07, 2007 1:16 pm

thanks for clarifying.

77amc · Post by **77amc** » Thu Dec 06, 2007 7:50 am

So, how does someone get ahold of this "forester" manifold.
Is it a canadian car/motor?
I have a couple of friends in Vancouver..
How do you like the NON power brake setup?

Thanks. E

Post by **DJpowerHaus** » Thu Dec 06, 2007 4:21 pm

The Forrester is an aftermarket intake manifold. Do a google search and you'll find pictures, prices, etc.
